System Area & Tile Layout
RIVIERA-XL – 203 sq. ft.
LAGUNA-XL – 253 sq. ft.
MALIBU-XL – 303 sq. ft.
DAYTONA-XL – 353 sq. ft.
Dimensions
RIVIERA-XL – 17’ L x 12’ W
LAGUNA-XL – 21’ L x 12’ W
MALIBU-XL – 25’ L x 12’ W
DAYTONA-XL – 29’ L x 12’ W
Design Conditions
Up to 150 MPH Wind Speed
50 PSF Snow Load
Weatherproof Structure
Front Clearance
6 ft. 11.5 in. (83.5 in.) – Short Side
10 ft. 2 in. (122 in.) – Tall Side
PV Tile Dimensions
1120 mm / 1260 mm x 465 mm x 8 mm
PV Tile Power
77 Wp & 90 Wp (+2%)
System Voltage: 600 V
Accessories
Recessed Lighting
Power Outlet
Premium Options: LED Lights
